Recently, our company has successfully delivered multiple sets of advanced laser concrete leveling machine to a professional agricultural construction enterprise in southern France, for the ground construction of its large-scale farm warehouses and agricultural machinery depots.【WhatsApp/WeChat/Phone】+86 13837122632
Hot-selling Laser Screed for Sale Parameters
| YG-ZP30 | |
| Engine brand model | Yanmar 4TNV94L |
| Type | Diesel |
| Power | 35.5KW/48hp |
| Fuel tank volume | 100L |
| Hydraulic oil volume | 150L |
| Hydraulic system | Danfoss |
| Laser transmitter | American Tempo |
| Laser receiver | German Mopar |
| Laser system control effect | Flat, inclined or double slope (3D) |
| Laser system control method | Microcomputer laser scanning |
| Trapping method | Hydraulic Cage Paving |
| Auger power | Hydraulic motor |
| Advantages of Jiaobanlong | Flip up and down for easy cleaning, left and right switching, blades made of highly wear-resistant material, more durable |
| Reach length | 6000mm |
| Vibrating plate width | 3100mm |
| Leveling thickness | 100-450mm |
| Walking weight/working speed | 4-8km/h 24m/min |
| Walking drive form | Hydraulic four-wheel drive Outrigger |
| Steering method | One-touch four-leg self-leveling |
| Walking tires | Front wheel + four wheels + crab walk |
| Cleaning machine flow | 15L/min |
| Body size | 5350x3650x2040mm |
| Weight | 5500 kgs |
Why Choose Laser Concrete Leveling Machine?
- Handling Large-area Construction
Traditional methods struggle to ensure the overall flatness of warehouse floors spanning thousands of square meters, while the laser concrete leveling machine achieves seamless, high-precision operation through full-area laser control.
- Meeting Load Requirements of Heavy Machinery
The ground of agricultural machinery parking areas needs to bear loads of dozens of tons, imposing extremely high requirements on the compactness of the base course and the levelness of the surface course. This equipment can complete vibration, leveling and compaction in one go.
- Improving Construction Efficiency
The automated equipment significantly reduces reliance on manual labor and accelerates project progress, which is the core factor that led the customer to make the decision after evaluating a variety of laser screed for sale.
How Does This Laser Concrete Leveling Machine Work?
This high-efficiency laser screed machine integrates a number of intelligent engineering technologies. Its core lies in that the reference plane signal set by the Trimble laser transmitter (USA) is captured in real time by the MOBA receiver (Germany) and transmitted to the on-board microcomputer. The computer calculates the deviation in milliseconds and drives the hydraulic system to automatically adjust the height and inclination angle of the leveling head, thus achieving precise construction without human error. Its 6-meter telescopic arm and 3.1-meter wide leveling head ensure high coverage per operation.
On-site Performance of Concrete Laser Leveling Machine
The person in charge of the French construction team specifically pointed out that several detailed designs of the equipment are impressive:
- First, the “soft landing” function avoids construction joints;
- Second, the 120-degree large-range swing of the leveling mechanism is extremely efficient in leveling concrete materials;
- Third, the one-click self-leveling function of the four hydraulic outriggers enables the equipment to quickly enter an optimal working state even on slightly uneven ground.
They praised this concrete laser leveling machine as a “thoughtful working partner”.
From Purchase to Operation: Building a Seamless Support System
- In-depth Pre-sales Technical Disclosure
Through 3D animations and video conferences, we explained to the customer in detail the equipment principle, construction process and maintenance key points, eliminating technical doubts.
- Customized Operation Training
Our engineers went to France for on-site teaching, ensuring that the operators can proficiently master all skills from laser system setup to daily maintenance.
- Establishing a Rapid Response Channel
Our professional team is available 24/7 to ensure that technical consultations are answered in a timely manner.
