At a large logistics center project in Warsaw, YG’s concrete laser leveling machine earned high praise from the Polish client for its outstanding performance. It not only greatly improved construction efficiency but also showcased the strength of Chinese manufacturing on the international stage. Contact us anytime for more product information and exclusive quotes!【WhatsApp/WeChat/Phone】+86 13837122632
Concrete Laser Leveling Machine Parameters
| YG-CL300 | |
| Engine model | Briggs & Stratton 38E3/LONCIN/Honda 690 (optional) |
| Engine type | Gasoline, air-cooled 4-stroke, twin-cylinder engine |
| Engine power | 22KW/30ps |
| Fuel capacity | 20L (operation time is about 8 hours |
| Hydraulic oil capacity | 37L |
| Laser transmitter | Swiss Leica/Tower transmitter (optional) |
| Laser receiver | Swiss Leica/Tower receiver (optional) |
| Laser system control effect | Plane, slope, double slope (three-dimensional) |
| Laser system control method | Microcomputer laser scanning |
| Paving method | Hydraulic stirring cage paving |
| Vibration method/excitation force | Hydraulic vibration/2000N |
| Vibration plate width | 2500mm |
| Leveling thickness | 50-300mm |
| Travel drive | Reducer motor integrated |
| Travel speed | 0-4Km/h (speed adjustable) |
| Travel tire | Solid anti-skid and anti-puncture tires (optional wide tires) |
| Body size | 3250x2850x1320mm |
| Body weight | 900Kg |
Project Background and Challenges
The Warsaw logistics center covers a total construction area of 85,000 m². The owner required the overall floor flatness deviation to be controlled within ±2 mm. Such strict precision, combined with a tight construction schedule, made traditional methods inadequate. After careful evaluation, the project team chose YG’s laser concrete leveling machine.
Why Choose YG Concrete Laser Leveling Machine
- The YG-CL300 laser screed machine is equipped with a four-wheel hydraulic drive system, ensuring stable performance even under complex site conditions. Compared with traditional models, it offers stronger power output and smoother movement, making it well-suited to Poland’s variable weather.
- Its microcomputer laser control system, powered by a Swiss Leica laser, guarantees industry-leading accuracy. This configuration gives YG’s laser screed for sale a significant advantage over competitors in the same price range.
- Moreover, YG provides complete technical support and after-sales service to keep the machine in optimal condition throughout the project—reducing operational risk and ensuring consistent performance.
Laser Concrete Leveling Machine’s Applications and Feedback
- During the project, the YG-CL300 concrete laser leveling machine demonstrated excellent performance, achieving an average of 3,000 m² per day—over 40% more efficient than traditional equipment. The project manager noted, “The laser concrete leveling machine is very easy to operate. Its front-seat design gives the operator a clear view, reduces labor intensity, and keeps performance stable during continuous operation.”
- The client also praised the machine’s precision: “We measured the completed floor areas, and the flatness deviation stayed strictly within ±2 mm, far exceeding expectations. The laser screed machine maintained outstanding consistency throughout construction and has become our new benchmark for future projects.”
- Notably, the machine’s low failure rate saved significant maintenance time. With only routine servicing required, it never caused project delays—allowing completion four weeks ahead of schedule and delivering excellent economic benefits.
FAQs about Concrete Laser Leveling Machine
What construction scenarios is the YG-CL300 applicable to?
Answer: This model works for small and medium-sized concrete floor projects requiring high precision. Typical application scenarios are listed below:
- Small factory and warehouse floors
- Commercial underground parking lots and supermarket ground slabs
- Courtyards, widened road sections, and garage ramps
- Agricultural facilities, including breeding farms and farm machinery garages
- Narrow construction sites needing frequent relocation
Its leveling thickness ranges from 50–300mm, capable of supporting floors under light to medium load conditions.
What engines can be fitted on this machine?
Answer: Gasoline engines from multiple brands are optional, including Briggs & Stratton 38E3, LONCIN, and Honda 690. Customers can pick options based on actual demands.
What advantages does YG-CL300 have compared with large laser screed machine such as YG-ZP30?
Answer:
- Lighter weight: 900 kilograms against 5500 kilograms, ideal for floor slab construction and tight spaces
- Gasoline power: Lower noise than diesel units, fit for indoor sites with strict emission standards
- Lower costs: Less initial purchase cost and fuel consumption than large-size equipment
- Easy relocation: Two workers can finish loading, unloading, and transportation
Is professional training required for operation? How hard is it to master?
Answer: The ride-on design eases operator fatigue. However, first-time operators need training covering laser system calibration, gradient setup, and routine maintenance like blade disassembly and cleaning. Experienced concrete workers can operate the machine independently after 1 to 2 days of coaching.
Partner with YG for Precision Construction
The success of the Poland project proves that YG’s concrete laser leveling machine excels in high-precision floor construction. Choosing YG means more than purchasing a laser screed for sale—it means partnering with a reliable expert in construction solutions. Experience YG’s superior performance firsthand and let our professional technology and dependable products help you build your next landmark project.
Contact us now for your customized plan and limited-time offer—partner with YG and set new industry standards!【WhatsApp/WeChat/Phone】+86 13837122632
