From coal yards to construction sites, from port docks to landfill sites, you can always see a dust suppression cannon rotating and spraying mist. It has been widely used in environmental protection, municipal administration, sanitation, landscaping, agriculture and forestry, solid waste treatment, steel mills, stone processing, and many other fields, even for large-area disinfection and epidemic prevention after major disasters. Whether the dust comes from crushing, loading, or transport, the dust control cannon can precisely deliver water mist to every dust source through flexible horizontal and vertical adjustment, truly earning the title of “mobile dust guard.”

Click Here for a Free Quote

Water Cannon Dust Suppression Parameters

Model	YG-20	YG-30	YG-40	YG-60
Spraying distance	20m	30m	40m	60m
Engine	electric	electric	electric	electric
Electric	380V/50HZ,3 phase	380V/50HZ,3 phase	380V/50HZ,3 phase	380V/50HZ,3 phase
Fan motor	3kw	3kw	4kw	11kw
Steering motor	2*1.5kw	2*1.5kw	2*1.5kw	2*1.5kw
Pump motor	1.5kw	1.5kw	2.5kw	7.5kw
Horizontal angle	360°	360°	360°	360°
Vertical angle	Minus10°-55°	Minus10°-55°	Minus10°-55°	Minus10°-55°
The nozzle	8	10	16	22
Cylinder material	Q235 Carbon steel	Q235 Carbon steel	Q235 Carbon steel	Q235 Carbon steel
Bucket		460L	480L	800L
Water consumption	1000L/h	1500L/h	3000L/h	7500L/h
Recycled water pipe	1400mm	1400mm	1400mm	1400mm
The machine size	1170*940*1700mm	1170*940*1800mm	1650*1200*2200mm	1700*1200*2200mm
Weight	200kg	250kg	300kg	350kg

Click Here for a Free Quote

Why Is the Dust Suppression Cannon a Cost-effective Dust Control Equipment?

1. Replacing manual labor: One dust control cannon can cover an area with a radius of dozens of meters, replacing 3-5 workers holding hoses. Based on monthly labor savings of $1,500-2,500, the equipment cost can be recovered in just a few months.
2. More economical than water trucks: The purchase cost of water cannon dust suppression is only 1/3 to 1/2 that of a water truck, with no need for a chassis or driver. The atomized droplets have a higher binding rate with dust, so the dust suppression effect is actually better.
3. Avoid environmental fines: The dust suppression efficiency reaches over 90%, helping projects consistently meet emission standards and avoiding shutdowns and fines caused by excessive dust.

Dust Control Cannon Water Consumption and Energy-Saving Advantages

Many customers worry that water cannon dust suppression “wastes water and electricity,” but the reality is quite the opposite:

1. High water efficiency in atomization: The high-pressure pump breaks water into tiny droplets that stay suspended longer and fully contact dust. The water consumption per unit area of water cannon dust suppression is only about 1/5 of that of direct water truck flushing. The water is all used for “wrapping and settling dust,” not just running off.
2. Controllable energy consumption with electric drive: The smallest model YG-20 has a total power of only about 6kW, costing less than $1 per hour to run. The largest YG-60 has a total power of about 21.5kW, matching its extensive coverage of 7500L/h and 60m range, yet the energy consumption per unit treatment area remains very low.
3. Return water design reduces waste: The standard 1400mm return pipe allows unsprayed water to recirculate and be reused.
4. Low maintenance cost: Nozzles are made of stainless steel (extra spare nozzles are included with shipment), the frame is galvanized for corrosion resistance, and daily maintenance only requires regular nozzle cleaning and pump inspection.

Ask For Details

Range Selection Comparison: 20m / 30m / 40m / 60m – How to Choose?

The core principle of selection is “match the working area.” Overkill in range is the most common waste.

• YG-20 (20m): Suitable for small construction sites, mixing plants, and localized dust points. It weighs only 200kg for easy relocation, has the lowest fog cannon price, and is ideal for customers with limited budgets or those trying mechanized dust suppression for the first time.
• YG-30 (30m): Suitable for medium-sized coal yards, stone processing plants, and construction sites. It offers a good balance between coverage and price, and is the best-selling model.
• YG-40 (40m): Suitable for large mines, steel mills, and medium-sized ports. It comes with a 460L water tank for continuous operation and has a water consumption of 3000L/h.
• YG-60 (60m): Suitable for port docks, large open-pit mines, and extra-large stockyards. With 22 nozzles and a high flow rate of 7500L/h, a single unit can cover over 10,000 square meters.

It is recommended to choose a range that is 20% larger than the maximum radius of the dust source, leaving some margin without paying extra for unused range.

Request Custom Solution

Frequently Asked Questions about Dust Suppression Cannon

Q1: Which has better dust suppression effect, the dust suppression cannon or the water truck?
The dust suppression cannon atomizes smaller droplets that stay suspended longer, with a higher binding rate with dust. Its dust suppression effect is significantly better than that of a water truck, and it uses less water.

Q2: What if there is no 380V power supply on site?
All four models are driven by 380V three-phase power. For sites without grid power, you can optionally equip it with a gasoline or diesel generator set.

Q3: How to perform daily maintenance?
Three main points: Clean the inlet filter after each use; regularly check the pump lubricant level; and when shutting down for long periods, drain water from the pipes and clean dust off the air duct cover and impeller.

Q4: What is the remote control range? Is it difficult to operate?
The standard remote control has an effective range of about 100 meters (in open areas), allowing you to control horizontal rotation and vertical tilt from a distance without needing to be near the unit. The control panel is clearly marked, and with simple training, anyone can operate it. One person can handle all spraying tasks.

Q5: What is the delivery time for water cannon dust suppression equipment?
Regular models are in stock and ship within 7-15 days after payment. Sea freight to port is supported.

Dust Suppression Cannon for Sale

YG Machinery now has the full range of 20-60m dust suppression cannons in stock for sale. The four models cover all dust control scenarios from small construction sites, mines, coal yards, steel and stone plants, to port docks. The YG-20 and YG-30 are lightweight, flexible, and affordable, suitable for small to medium-sized projects with limited budgets. The YG-40 and YG-60 offer long range and high flow, ideal for large-area continuous operations. All units come standard with wireless remote control, 360° rotation, and -10° to 55° tilt adjustment. The frame is galvanized for corrosion resistance, the air duct cover is cold-rolled steel plate, and the fan blades are aluminum alloy, ensuring durability. Regular models are in stock and ship within 7-15 days after payment, with sea freight to port supported. If you need optional configurations like diesel generator sets, trailer chassis, or ceramic pumps, just specify when ordering, and we’ll include them all. If you are inquiring about fog cannon price, tell us your site area, dust type, and power conditions, and the YG sales team will give you model recommendations and a formal quotation within 24 hours. Welcome to inquire and order.
