When pursuing efficiency and quality, you no longer have to choose between the two. A professional automatic cement plaster machine can simultaneously achieve precise control of wall flatness and significantly shorten the overall construction period through intelligent construction.
Parameters of YG Wall Plastering Machine for Sale
| voltage | DC48V |
| power supply mode | battery |
| Standard battery capacity | 30AH |
| Mechanical arm size (length * width * height) mm | 242*120*1800 |
| Host size (length * width * height) mm | 700*550*1050 |
| Overall dimension (length * width * height) mm | 850*550*1850 |
| Spatula length m | 1.3 meters |
| Smoothing height m | 3 meters, 4 meters, 5 meters, 6 meters |
| Total weight Kg | one hundred and eighty |
How Does the Automatic Cement Plaster Machine Achieve “One Wall, One Smooth Plaster”?
- High-precision sensing system: The highly sensitive attitude sensor at the top of the automatic cement plaster machine is like the “eyes” of the machine. It can real-time monitor the relative position and angle between the robotic arm and the wall to ensure accurate benchmarks.
- Intelligent logic control system: The built-in logic programming controller acts as the “brain”. It receives signals from the sensor and immediately calculates the instructions that need to be adjusted. Users can intuitively set parameters through the touch-screen human-machine interaction system.
- Servo-driven execution system: The brushless servo motor provides stable torque to drive the attitude adjustment mechanism, enabling the robotic arm equipped with the trowel to quickly and automatically level. The lifting system controls the steel wire rope through the servo motor, driving the trowel to move vertically at a constant speed to complete the one-time smoothing of the entire wall without manual screeding.
How Does the Automatic Cement Plaster Machine Help Save Materials and Time in Projects?
- Precise control to reduce material waste: The machine applies plaster with a uniform thickness, avoiding the common problem of uneven thickness in manual construction, and can save about 10%-15% of mortar materials.
- Continuous operation to greatly shorten the construction period: The smoothing efficiency of one machine can reach 5-8 times that of manual work. Based on 8 working hours a day, it can complete the plastering of hundreds of square meters of walls, which is especially suitable for residential projects with batch delivery.
- Reduce comprehensive labor costs: Only 1-2 people are needed to operate one house plastering machine, which can replace the entire plastering team. This greatly eases the pressure of skilled worker shortage and reduces management and labor costs.
Tips to Extend the Service Life of the Automatic Cement Plaster Machine
- Timely and thorough cleaning after operation: After each construction, be sure to thoroughly rinse the trowel, robotic arm and conveying pipeline with clean water before the mortar is completely solidified. This prevents material solidification and hardening from causing component damage or blockage.
- Regular inspection and fastening: Check whether the bolts at each connection part are loose every day; check whether the steel wire rope is worn every week, and whether the transmission components need to be filled with grease.
- Maintenance of battery and electrical system: Follow the battery maintenance specifications to avoid over-discharging. Regularly check the circuit connectors to prevent poor contact caused by moisture or dust.
- Proper storage and transportation: When the automatic wall cement plastering machine is not in use, it should be stored in a dry environment. During transportation, use its quick-dismantling function to properly fix the components to avoid bumps and collisions.
Why Choose YG House Plastering Machine?
- Solid and reliable technology: It adopts an aviation aluminum robotic arm and a servo system to ensure construction accuracy and equipment durability.
- Strong intelligent adaptability: The self-adaptive chassis and high-precision sensing system do not require screeding, and can work stably under various ground conditions.
- Simple operation and maintenance: The touch-screen interaction is intuitive, and the modular design facilitates disassembly, assembly and transportation, effectively improving the use efficiency.
- Continuous service upgrade: It provides the possibility of IoT upgrade and comprehensive after-sales support to protect your long-term investment value.
