The Cement Mortar Spray Machine with mixing function not only integrates material preparation and spraying application, but also realizes continuous, uniform and high-pressure mechanized operation, bringing a leap-forward improvement to construction efficiency. This article will provide you with a comprehensive analysis of the core technology and application value of this equipment, revealing how it becomes an ultimate tool to ensure construction period, control cost and improve quality.【WhatsApp/WeChat/Phone】+86 13837122632
Cement Mortar Spraying Machine Parameters
| Parameter Item | Specification |
| Delivery Flow Rate | 0-60L/min |
| Maximum Pressure | 3MPa |
| Applicable Material Ratio (Water:Cement:Sand) | 0.7–1:1:3 |
| Power | 4kw |
| Passable Particle Size | ≤4mm |
| Delivery Distance | 50m horizontally, 40m vertically |
| Hopper Capacity | 60L |
| Air Compressor Displacement | 0.3m³/min |
| Working Voltage | 220-380v |
| Overall Machine Weight | 360kg |
Dual-motor Design of the Cement Mortar Spray Machine
The core innovation of this Mortar Spraying Machine lies in its efficient dual-motor independent drive system. This design forms the cornerstone of the equipment’s efficient and stable operation:
- Independent Mixing Motor: Dedicated to driving the mixing blades in the hopper, it ensures that materials such as putty powder and cement mortar are evenly mixed before delivery, preventing sedimentation and segregation, and providing slurry with consistent quality for continuous spraying.
- Independent Spraying & Pumping Motor: Responsible for providing stable high pressure to deliver slurry to the spray gun through pipelines. The dual motors have clear division of labor and do not interfere with each other. Even under high-intensity continuous operation, they can ensure the dual stability of mixing force and delivery pressure, which is an advantage incomparable to ordinary single-motor equipment.

Integrated Advantages of the High-performance Cement Mortar Spray Machine
Based on the reasonable overall design, this Cement Mortar Spraying Machine realizes the integrated integration of the pumping system and air compression system, thus bringing multiple performance improvements:
- Easy to Move & Quick to Deploy: The integrated design makes the equipment compact in structure, easy to transfer between building floors on construction sites, and quickly respond to the construction needs of different working faces.
- Continuous & Stable Feeding: Advanced pumping technology effectively eliminates the pulse phenomenon and achieves linear continuous output of slurry. This makes the spraying surface extremely uniform without intermittent marks, and at the same time enhances the adhesion of the coating to the substrate.
- Simple Operation & Maintenance: The silent air compressor equipped on the equipment adopts a maintenance-free design. Users only need to connect the power supply to use it, without complicated oiling and maintenance, which greatly reduces operation and maintenance costs and operational complexity.

Multi-material Adaptability of the Mortar Spraying Machine
The value of an excellent Mortar Sprayer Machine is largely reflected in its wide material compatibility. This equipment is by no means limited to cement mortar spraying:
- Core Material Handling Capacity: As a high-efficiency Cement Mortar Spraying Machine, it can perfectly handle traditional materials such as cement mortar and dry-mix mortar with standard ratios.
- Extended Application Range: Its technical design is also suitable for spraying putty powder, coatings, latex paint, real stone paint, as well as various functional water-soluble materials such as thermal insulation mortar, waterproof, fireproof and thermal insulation materials, truly achieving multi-purpose with one machine.
