This advanced YG core drilling rig combines modern hydraulic technology with precision mechanical design, making it suitable for operations ranging from shallow detection to deep exploration. Whether for metal mineral prospecting or hydrogeological investigation, the YG series provides efficient drilling solutions. If you are looking for a high-performance core drill rig for sale, feel free to contact our professional team for model recommendations and a customized quotation!【WhatsApp/WeChat/Phone】+86 13837122632
YG Core Drill Rig for Sale Parameters
| Parameter Category | YG-400 | YG-600 | YG-800 | YG-1000 |
| Drilling Capacity | Diameter: HTW-NTW-BTW; Depth: 180-400-500 (M) | Diameter: HTW-NTW-BTW; Depth: 200-600-650 (M) | Diameter: HTW-NTW-BTW; Depth: 400-800-1000 (M) | Diameter: HTW-NTW-BTW; Depth: 500-1000-1100 (M) |
| Hydraulic System | Rated Pressure: 21 (MPA); Rated Flow: 168 (L/min); Cooling: Air + Water | Rated Pressure: 21 (MPA); Rated Flow: 192 (L/min); Cooling: Air + Water | Rated Pressure: 25 (MPA); Rated Flow: 260 (L/min); Cooling: Air + Water | Rated Pressure: 28 (MPA); Rated Flow: 300 (L/min); Cooling: Air + Water |
| Engine | Brand: Yuchai; Type: Turbocharged; Rated Speed: 2400 (RPM); Power: 78 (KW) | Brand: Yuchai; Type: Turbocharged; Rated Speed: 2400 (RPM); Power: 92 (KW) | Brand: Yuchai; Type: Turbocharged; Rated Speed: 2400 (RPM); Power: 92 Six-cylinder (KW) | Brand: Cummins; Type: Turbocharged; Rated Speed: 2400 (RPM); Power: 154 Six-cylinder (KW) |
| Power Head | Max Torque: 300-500 (N.M); Max Speed: 1300 (RPM); Feed Stroke: 1900 (MM) | Torque: 450-1000 (N.M); Speed: 1300 (RPM); Feed Stroke: 1900 (MM) | Torque: 950-1300 (N.M); Speed: 1300 (RPM); Feed Stroke: 2400 (MM) | Torque: 1000-3500 (N.M); Speed: 1300 (RPM); Feed Stroke: 3500 (MM) |
| Mast | Type: Ground-contact Integrated Tower; Drilling Angle: 0-90 (°); Lifting Force: 12 (T); Feeding Force: 6 (T) | Type: Ground-contact Integrated Tower; Drilling Angle: 45-90 (°); Lifting Force: 16 (T); Feeding Force: 8 (T) | Type: Ground-contact Integrated Tower; Drilling Angle: 45-90 (°); Lifting Force: 24 (T); Feeding Force: 12 (T) | Type: Ground-contact Integrated Tower; Drilling Angle: 45-90 (°); Lifting Force: 30 (T); Feeding Force: 15 (T) |
| Hoist | Lifting Force: 500 (KG); Speed: 100-240 (RPM); Wire Rope Dia: 6 (MM); Capacity: 500 (M) | Lifting Force: 600 (KG); Speed: 100-300 (RPM); Wire Rope Dia: 6 (MM); Capacity: 600 (M) | Lifting Force: 600 (KG); Speed: 100-300 (RPM); Wire Rope Dia: 6 (MM); Capacity: 800 (M) | Lifting Force: 1000 (KG); Speed: 100-300 (RPM); Wire Rope Dia: 6 (MM); Capacity: 1000 (M) |
| Travel | Type: Manual + Remote Control; Speed: 2.5 (KM/H); Gradeability: 45 (°) | Type: Manual + Remote Control; Speed: 3.5 (KM/H); Gradeability: 45 (°) | Type: Manual + Remote Control; Speed: 3.5 (KM/H); Gradeability: 45 (°) | Type: Manual + Remote Control; Speed: 3.5 (KM/H); Gradeability: 45 (°) |
| Hydraulic Mud Pump | Flow: 30-90 (L/min); Pressure: 4-7 (MPA) | Flow: 30-90 (L/min); Pressure: 4-7 (MPA) | Flow: 90-180 (L/min); Pressure: 4-7 (MPA) | Flow: 90-180 (L/min); Pressure: 4-7 (MPA) |
| Transport Size | 4000×1900×1800 (MM) | 4000×2000×1800 (MM) | 5500×2100×2000 (MM) | 6000×2200×2400 (MM) |
| Weight | 4.3 (T) | N/A | 6.5 (T) | 7.5 (T) |
Core Drilling Rig Advantages
- Full hydraulic transmission system: Adopts advanced hydraulic technology to achieve stepless speed regulation and precise control. The drilling process is smooth, efficient, and far superior to traditional mechanical rigs.
- Ground-contact multi-angle tower design: The tower’s direct ground-contact structure provides excellent stability and supports 0–90° multi-angle drilling, adapting to various terrains and drilling requirements while greatly expanding its application range.
- Thin-wall diamond wireline coring technology: This advanced process ensures a high core recovery rate, reduces downhole accidents, and improves operational safety—key to obtaining high-quality geological data.
Core Drilling Rig Details
- High-efficiency Yuchai engine: Equipped with a branded engine delivering strong power with low fuel consumption, providing a stable and reliable power source for the entire hydraulic system and ensuring continuous operation even under harsh conditions.
- Hydraulic power head system: Features a rod anti-detachment function and high thrust force to ensure stable and reliable drilling, greatly reducing operational risks and maintenance needs.
- Hydraulic winch device: Enables precise lifting and lowering through the winding and unwinding of the steel wire rope. It is easy to operate, reliable, and effectively improves core extraction efficiency.
- Engineering crawler chassis: Designed with an engineering-grade crawler track that ensures stability and strong climbing ability, allowing the equipment to move smoothly across complex terrains.
Key Differences Between Full Hydraulic Core Drilling Rig and Vertical Shaft Core Drilling Rig
- Function and application scope: The vertical shaft model features dual functionality—it can perform both coring and water well drilling, but requires different accessory systems. The full hydraulic model, however, is a specialized machine designed only for coring (mainly wireline coring) and focuses on geological exploration. The YG series core drilling rig is specifically engineered for high-standard core sampling.
- Applicable depth and operational capability: The full hydraulic type is mainly suitable for deeper drilling (the YG series reaches up to 1100 meters), showing excellent performance in deep operations. In contrast, vertical shaft rigs are generally used for shallower drilling (below 150 meters). This difference in drilling depth leads to distinct application scenarios.
- Specialization and process requirements: The YG full hydraulic drilling rigs adopt specialized wireline coring technology to ensure core quality in deep drilling. Vertical shaft rigs, on the other hand, require tool and accessory changes when drilling water wells, offering greater versatility but lower specialization.
The YG series core drill rig for sale, with its advanced technology, reliable performance, and outstanding adaptability, is an ideal choice for geological exploration. Whether you need a high-efficiency drilling rig for borehole or are assessing borehole drilling machine price and value, the YG series provides a satisfying solution. Its combination of reasonable cost and excellent performance ensures the best investment return. Contact our professional team today to get a tailored drilling rig for borehole configuration and start a new chapter of efficient exploration!【WhatsApp/WeChat/Phone】+86 13837122632
