Empower your excavator and unlock its hidden handling potential. The hydraulic magnet for excavator is more than just an attachment; it is the core equipment that upgrades a regular excavator into a multi-functional handling expert. It eliminates the need for complicated external power supplies and leverages the excavator’s own hydraulic power to achieve precise control over steel materials.【WhatsApp/WeChat/Phone】+86 13837122632
YG Excavator Magnet Attachment Specifications
| Item/Model | Unit | YG02 | YG04 | YG06 | YG08 | YG10 | YG14 | YG20 |
| Suitable Excavator | ton | 4-6 | 7-11 | 12-16 | 17-23 | 24-30 | 31-40 | 41-50 |
| Weight | kg | 1400 | 1500 | 1890 | 2000 | 2200 | 2500 | 2800 |
| Outer Diameter | mm | 700 | 800 | 900 | 1100 | 1200 | 1300 | 1400 |
| Working Flow | lpm | 30-55 | 50-100 | 90-110 | 100-140 | 130-170 | 200-250 | 250-320 |
Why Choose a Hydraulic Magnet for Excavator?
- Ultimate Convenience & Integrated Power: The hydraulic magnet for excavator is directly driven by the excavator’s built-in hydraulic system, requiring no external power supply or additional generator installation. This “plug-and-play” design greatly simplifies the deployment process and cuts down equipment investment costs.
- Robust & Durable: Core components are made of Q345 high-strength manganese steel plates, delivering excellent impact resistance and corrosion resistance. Combined with the semi-permanent hydraulic pipeline design, it effectively reduces daily maintenance frequency and long-term operational costs.
- Safe & Efficient Operation: Precise control is achieved via the valve block inside the cab. Operators can easily start/stop the magnetism and load/unload materials in an instant. A single operator can handle heavy-duty tasks, significantly boosting operational safety and efficiency.
What Are the Core Applications of a Hydraulic Magnet for Excavator?
- Scrap Steel Yards: Quickly sort, load, unload and transfer scattered scrap steel and end-of-life vehicles.
- Construction Sites: Efficiently handle and stack construction materials such as steel bars, section steel and steel plates.
- Ports & Logistics Centers: Load and unload heavy ferrous cargo like steel coils, cast iron parts and metal containers.
- Metal Processing Workshops: Transfer raw materials and finished products, and feed materials within the workshop.
How to Select the Right Hydraulic Magnet for Excavator?
- Match Excavator Tonnage: Choose the corresponding magnet model based on your excavator’s tonnage (e.g., YG06 for 12–16 ton excavators). This ensures stable operation of the excavator’s hydraulic system and optimal equipment stability.
- Check Performance Parameters: Pay attention to the magnet’s diameter (which determines adsorption area and single-load capacity), as well as the required working flow and pressure. Ensure compatibility with the excavator pump’s output parameters.
- Consider Material Type: For light, thin and scattered materials, select a larger-diameter model to increase coverage. For heavy single-piece materials, ensure the magnet’s magnetic center and lifting capacity are sufficient.
How to Maximize Efficiency with a Hydraulic Excavator Magnet?
- Plan Operation Routes: Map out routes for material picking, transferring, stacking and loading in advance to reduce empty travel and rotation time of the equipment.
- Layered Adsorption Technique: For piled bulk materials, adopt a top-down layered adsorption method. It is more efficient and safer than trying to lift materials from the bottom in one go.
- Coordinate with Loading Operations: During loading, take advantage of the excavator’s flexibility to extend the magnet into the truck bed for precise unloading, achieving high-density use of the truck space.
Maintenance of Excavator Magnet Attachment
- Regular Lubrication & Anti-corrosion: Apply grease to rotating parts as instructed to ensure smooth movement. When the magnet is idle for a long time, apply anti-rust oil to the magnetic pole surface.
- Monitor Hydraulic System: Ensure the hydraulic oil of the main excavator is clean. Regularly inspect the attachment-specific hydraulic pipelines to prevent aging and cracking.
- Arrange Professional Inspections: Have technicians conduct a comprehensive inspection of the hydraulic scrap magnet’s structure, welds and sealing performance after a certain period of operation or at least once a year.
The hydraulic excavator magnet is by no means a simple functional add-on. Through in-depth integration, it transforms a regular excavator into a multi-functional, high-efficiency material handling expert. Whether it is for scrap steel recycling, construction material sorting or port loading and unloading, choosing the right hydraulic excavator magnet will be a key step to reduce costs, improve efficiency and enhance your core competitiveness. Contact us for a customized quote!【WhatsApp/WeChat/Phone】+86 13837122632
