As an innovative excavator attachment, the Hydraulic Rock Drill and Splitter is reshaping hard rock processing technology with its unique integrated “drilling + splitting” operation mode. Combining drilling and static splitting functions in one, it is powered by an excavator to achieve precise and continuous rock breaking under complex working conditions, making it a powerful assistant in the modern engineering field.【WhatsApp/WeChat/Phone】+86 13837122632
Advantages of Using the Hydraulic Rock Drill and Splitter
- Efficient Integration: Seamlessly connects drilling and splitting processes, greatly reducing equipment switching time and improving overall operation efficiency.
- Safe and Environmentally Friendly: Adopting the principle of static hydraulic splitting, the construction process involves no blasting vibration, no flying rocks, and low noise and dust, providing high safety guarantee.
- Precise and Controllable: Enables precise splitting in predetermined directions and sizes, with minimal impact on surrounding structures, making it particularly suitable for projects requiring precise control.
- Economical and Durable: With a robust structure, simple maintenance, and low operating costs, it can work continuously under high intensity, offering a high return on investment.
- Strong Adaptability: Modular design allows quick adaptation to various models of excavators, and it can operate flexibly in narrow or rugged sites.
Wide Application Scenarios of the Hydraulic Rock Drill and Splitter
- Mining: Used for silent mining of precious stones such as marble and granite, improving the yield rate of rough stone.
- Municipal Construction: For rock breaking close to residential areas or facilities in building foundation excavation, pipeline laying, and subway tunnel construction.
- Transportation Engineering: For hard rock treatment and tunnel excavation in highway and railway subgrades.
- Emergency Rescue: For quickly and safely removing boulder obstacles in geological disaster relief.
- National Defense Construction: Meets the strict requirements of silent and precise rock breaking for special projects.
The Rock Drilling and Splitting Machine vs. Other Methods
- Compared with Traditional Blasting: Completely avoids problems such as blasting permits, dangerous goods management, and shock wave hazards, achieving “silent” construction with a simple approval process and immediate start of work.
- Compared with Hydraulic Breakers: The impact force of hydraulic breakers is likely to cause internal damage to rocks and generate extremely high noise. In contrast, the hydraulic rock drill and splitter uses static splitting to concentrate force, maintain rock integrity, and create a friendly working environment.
- Compared with Manual Rock Breaking: Manual methods such as jackhammers are extremely inefficient and labor-intensive. The hydraulic rock drill and splitter realizes mechanized operation, which can be easily completed by a single person, improving efficiency by dozens of times and fundamentally ensuring personnel safety.
Technical Parameters of YG’s Hot-Selling Drilling and Splitting Machine
YG-130: suitable for 20-36 ton excavators
| Parameter Item | Unit | Value |
| Piling Beam Length | mm | 3875 |
| Drilling Advance Stroke | mm | 2000 |
| Max Drilling Thrust Force | KN | 50 |
| Max Drilling Pull Force | KN | 32 |
| Piling Advance Stroke | mm | 1500 |
| Max Piling Thrust Force | KN | 160 |
| Max Piling Pull Force | KN | 100 |
| Hydraulic Pressure (Max) | MPa | 35 |
| Hydraulic Flow | L/min | 240 |
| Weight | kg | 4200 |
| Dimensions | mm | 4210×1400×1785 |
| Operation Mode | – | Remote Control |
Consult Now to Customize Your Solution
No matter what kind of hard rock challenges you are facing, our professional team can provide you with the most suitable configuration suggestions and construction guidance for the Excavator Rock Drill and Splitter. Choosing our Rock Drilling and Splitting Machine means choosing an efficient, safe and reliable partner. Welcome to contact us at any time to obtain detailed product information, on-site demonstrations or exclusive plan quotes, and jointly promote cost reduction and efficiency improvement of your engineering projects.【WhatsApp/WeChat/Phone】+86 13837122632
