The small tractor loader backhoe perfectly integrates front-end loading and rear-end digging functions, specially designed for confined spaces and mixed-task scenarios. For users who need a small front end loader with backhoe, understanding its unique working principle and all-around performance is key to making a smart investment.
Front Loader Backhoe for Sale Specifications
| YG30-25 Backhoe Loader(Articulated) | |
| Overall Dimension | |
| Length*Width*Height | 7070*2300*3769(mm) |
| Cab roof height | 2900(mm) |
| Wheel base | 2250(mm) |
| Track | 1640(mm) |
| Min.ground clearance | 300(mm) |
| Main Technical Specification | |
| system pressure | |
| load hydraulic system | 18Mpa |
| system flow | 120L/min |
| four-wheel drive,whole hydraulic system | four-wheel drive,whole hydraulic system |
| total operating weight | 7600kg |
| maximum speed | 22Km/h |
| maximum gradient capacity | 30° |
| loading bucket capacity | 1.0 m³ |
| rated loading | 2000KG |
| maximum articulated height of bucket | 3400(mm) |
| bucket discharge height | 2795(mm) |
| bucket discharge distance | 1048(mm) |
| loading lift capacity | 25KN |
| maximum tractive force | 39KN |
| maximum breakout force | 38KN |
| backacter bucket capacity | 0.3m³ |
| backacter discharge height | 3878(mm) |
| maximum digging depth | 4000（mm） |
| maximum digging radius | 5688(mm) |
| bucket slewing angle | 190° |
| bucket digging capacity | 46KN |
| bucket stick digging capacity | 31KN |
Working Principle and Core Structure of the Small Tractor Loader Backhoe
- Independent and Collaborative Modular Design: Its rear excavator module can fold to act as counterweight, while the sturdy loading mechanism provides a stable base for digging during front-end loading operations. The two systems work independently without interference, yet support each other mechanically, unifying functionality and stability.
- Efficient Sliding-Type Digging Mechanism: Unlike traditional fixed turntables, the digging arm uses a sliding design that allows the bucket to move sideways and fold. This not only expands the working range for side digging close to walls or obstacles, but also greatly improves adaptability in narrow terrain.
- Integrated Hydraulic and Control Center: The whole machine is driven by a single full-hydraulic system. With an ergonomic one-to-two multi-way valve control handle, the operator can easily achieve precise control of loading, lifting, and combined digging movements, with intuitive and simple operation.
4 Key Features of the Small Tractor Loader Backhoe
- Extreme Space Adaptability: Its compact structure is the primary feature, enabling flexible turning and operation in yards, greenhouses, narrow streets, and other areas inaccessible to large equipment.
- Seamless Operation Experience: The cab seat rotates 360 degrees, so the operator always faces the working direction when switching modes without repositioning the machine — safe and efficient.
- Strong Function Expansion Potential: The machine is equipped with auxiliary hydraulic lines for quick connection to hydraulic rammers, augers, log grapples, and other attachments, upgrading from a basic unit to a true multi-purpose work platform.
- Economical Maintenance Cost: With a relatively simple structure and clear layout of main systems, daily maintenance and troubleshooting are easier than large dedicated equipment, effectively reducing long-term ownership costs.
How All-in-One Performance Greatly Improves Team Efficiency
- Intensive Capital Investment: The one-time cost of a front loader and backhoe tractor is much lower than buying a small loader and excavator separately, greatly easing financial pressure.
- Doubled Equipment and Labor Efficiency: One machine and one operator can complete trenching, loading, backfilling, grading, and other processes, avoiding idle equipment and waiting time, and significantly improving work hour utilization.
- Lower Overall Operating Costs: Managing one machine is far more economical and convenient than coordinating two in terms of fuel consumption, transportation, parking space, and basic maintenance.
Versatile Applications of the Small Tractor Loader Backhoe in Emergency and Municipal Fields
- Emergency Rescue: Quickly performs road clearance, debris removal, flood control embankment reinforcement, and drainage trench digging, playing a critical role in key situations.
- Municipal Maintenance: Efficiently completes snow removal in winter, branch and leaf loading, ditch unclogging, and excavation for small municipal facilities.
- Agriculture and Site Management: Suitable for farmland water conservancy, ranch ditch cleaning, livestock farm bedding handling, and various site leveling and renovation.
How to Choose the Right front loader and backhoe tractor for You
- Match Core Working Conditions: Prioritize digging depth, loading bucket capacity, and overall power based on your most frequent tasks (more deep digging or heavy loading).
- Consider Actual Environment: Evaluate ground clearance, turning space, and access conditions of your main worksites, and choose a suitable size and drive type (4WD offers wider adaptability).
- Verify Reliability and Support: Prefer brands with good market reputation, and confirm reliable after-sales service and parts supply in your area.
Daily Maintenance Guide
- Before Each Start: Walk around inspection — check engine oil, hydraulic oil, coolant levels, and look for abnormalities, damage, or leaks on tires, hoses, and structural parts.
- Regular Lubrication and Cleaning: Strictly lubricate all points (hinge pins, swing shafts) per the manual. After work, clear mud and debris from the radiator, cab area, and traveling parts to prevent overheating and corrosion.
- Follow Scheduled Maintenance Strictly: Replace oil, hydraulic oil, filters, and other consumables on time — the most effective investment to protect the machine and avoid major failures.
Don’t let complicated processes slow down your project. A reliable small tractor loader backhoe is the key to breaking your efficiency bottleneck. Contact YG now for a customized solution and the latest front loader backhoe for sale quotation — start efficiency today.
