In the modern power support system, noise control has become as important as power supply reliability. The silent generator set is an efficient solution developed to meet this demand. It not only inherits the stability and high performance of traditional diesel engine generator set, but also greatly reduces operating noise through advanced noise reduction technology, allowing it to be widely used in places with strict acoustic requirements, making it an ideal backup power choice for hospitals, data centers, high-end hotels and communities.【WhatsApp/WeChat/Phone】+86 13837122632
Industrial Power Generator Parameters
| Power | 30kw | 100kw | 150kw | 200kw | 300kw | 400kw |
| cylinders | 4 cylinder | 6 cylinder | 6 cylinder | 6 cylinder | 6 cylinder | 6 cylinder |
| voltage | 400/230V | 400/230V | 400/230V | 400/230V | 400/230V | 400/230V |
| Frequency Range | 50HZ | 50HZ | 50HZ | 50HZ | 50HZ | 50HZ |
| Rotating speed | 1500rpm | 1500rpm | 1500rpm | 1500rpm | 1500rpm | 1500rpm |
| Cylinder diameter *stroke (mm) | 100*115 | 105*125 | 105*130 | 126*130 | 126*155 | 135*160 |
| Rated current | 54A | 180A | 270A | 360A | 540A | 720A |
| Phase | Three-phase four-wire | Three-phase four-wire | Three-phase four-wire | Three-phase four-wire | Three-phase four-wire | Three-phase four-wire |
How to Choose the Right Silent Generator Set?
To select an excellent silent generator set, comprehensive consideration is needed beyond basic power matching:
- Clarify noise level requirements: Different scenarios (such as residential areas, hospitals, field camps) have different noise limits. Confirm whether the sound pressure level (decibel value, dB(A)) of the unit at 1 meter or 7 meters complies with local regulations or project standards.
- Check the noise reduction technology level: Understand whether its noise reduction design is basic shielding or multi-layer high-efficiency sound insulation. This directly affects the actual silent effect during full-load operation.
- Balance power and silent volume: Higher silent standards often mean larger and heavier soundproof enclosures. Evaluate whether the installation space can accommodate the unit and whether necessary handling conditions are available.
- Focus on brand and overall performance: Choose brands with profound technical accumulation in the diesel engine generator set field, ensuring that its silent models also perform well in core power, heat dissipation balance and long-term reliability.


The “Noise Reduction Secrets” of the Silent Generator Set
The excellent silent performance of a high-quality silent diesel generator set comes from the coordination of the following three core technologies:
- High-efficiency soundproof enclosure: Adopts a multi-layer composite structure, lined with high-density sound-absorbing cotton and covered with galvanized steel or aluminum alloy. It effectively absorbs and blocks medium and high-frequency air noise generated by the engine and generator.
- Optimized muffler system: Equipped with industrial-grade exhaust mufflers. The internal multi-stage expansion chambers, sound-absorbing glass wool and other structures greatly reduce low-frequency roar caused by exhaust pulses, which is a key part of noise reduction.
- Professional shock absorption design: High-performance shock absorbers are installed between the engine and the base to block structural vibration transmission. Meanwhile, shock absorption devices are also used at the contact points between the whole unit and the ground, reducing solid vibration noise from the source.
Does the Soundproof Enclosure of the Silent Generator Set Affect Heat Dissipation?
This is the most common concern of users about silent generator set. Excellent design can perfectly balance the two:
- Scientific air duct design: The silent enclosure is not completely sealed. It is equipped with carefully calculated air inlets and outlets, guiding cold air to flow through high-temperature areas such as engine cylinders and radiators to form an efficient cycle.
- High-power cooling fan: Matched with larger displacement cooling fans to ensure sufficient air volume for forced heat dissipation even in a soundproof environment.
- Temperature control monitoring and protection: The unit is equipped with an intelligent temperature control system to monitor the internal temperature in real time. If the temperature is too high, the system will increase the fan speed or issue an alarm to ensure that the diesel engine, the core of the industrial power generator, always works within a safe temperature range.


Core Application Scenarios of Silent Diesel Generator Set
With its “powerful and quiet” features, the silent generator set plays an irreplaceable role in the following scenarios:
- Night municipal construction: Does not disturb residents, complies with urban noise control, and supports 24-hour continuous operation.
- Hospitals and schools: Ensures a quiet environment while providing uninterrupted backup power.
- Hotels and office buildings: Emergency power supply without affecting operation and living experience.
- Outdoor exhibitions and events: Supplies power for stages, sports events and commercial activities quietly without destroying the on-site atmosphere.
- Industrial plant backup: Stable power supply during power rationing and equipment maintenance.
Silent power is within reach. No need to compromise between power and noise. Contact YG now to get a customized configuration plan and experience the true meaning of “powerful performance, silent operation”. Let professional silent power support your business and peace of mind.【WhatsApp/WeChat/Phone】+86 13837122632
