Whether it’s curtain wall renovation in Italian old city redevelopment or glass and marble slab processing lines in industrial plants, heavy slab handling always determines the overall construction progress and finished product quality rate. Ordinary lifting equipment has insufficient suction, poor stability, and cannot handle heavy loads, easily causing damage to expensive slabs. Professional heavy glass lifting equipment is specifically designed for heavy slab construction, with balanced suction, smooth lifting, and a high safety factor.

Click Here for a Free Quote

Glass Lifting Machine for Sale Parameters

Model Type		YG-LD-300	YG-LD-400	YG-LD-500	YG-LD-600	YG-LD-800
Load Capacity		300kg(retract)150kg(extend)	400kg(retract)200kg(extend)	500kg(retract)250kg(extend)	600kg(retract)300kg(extend)	800kg(retract)400kg(extend)
Lifting Height		3500mm	3500mm	3700mm	3700mm	4500mm
QTY of Suction Cap		4pcs	4pcs	6pcs	6pcs	8pcs
Rubber Suction Cap		300mm	Ø300mm	Ø300mm	Ø300mm	Ø300mm
Maintenance-free Battery		2x12V/80AH	2x12V/100AH	2x12V/120AH	2x12V/120AH	2x12V/120AH
Battery Charger		Smart Charger	Smart Charger	Smart Charger	Smart Charger	Smart Charger
Drive motor		24V/1200W	24V/1200W	24V/1200W	24V/1200W	24V/1200W
Lifting Motor		24V/2000W/6L	24V/2000W/6L	24V/2000W/6L	24V/2000W/6L	24V/2000W/12L
Chassis L*W		2660*810mm	2660*810mm	2800*810mm	2800*810mm	2800*810mm
Driving Wheel		Ø250x80mm	Ø250x80mm	Ø300x100mm	Ø300x100mm	Ø300x125mm
Packing Size(mm)		2560*1030*1700	2560*1030*1700	2580*1050*1700	2580*1050*1700	3000*1250*2300
N.W/G.W		1100/1150kg	1280/1330kg	1300/1350kg	1400/1450kg	1600/1650kg
Loading Qty		1x20GP/40GP: 6SETS/12SETS
Movement	Automatic(4 kinds)	1. The suction cup frame flips 180° electrically. 2. The support plate automatically retracts. 3. Hydraulic arm lifts electrically. 4. The base of the whole machine moves 100-150mm horizontally.
	Manual (2kinds)	1. The suction cup holder can be manually rotated 90 degrees (electrically powered optional). 2. The suction cup holder can be manually rotated 360 degrees (electrically powered optional).
Usages		Mainly used for the handling, movement, and installation of materials such as glass, marble, wood, iron plate, etc.

Get Technical Specs

Case 1: Heavy Glass Lifting Equipment Solves High-rise Heavy Glass Installation Challenges

Client background:
The client is an Italian curtain wall engineering company that undertakes glass curtain wall renovation projects for commercial buildings in Milan, Turin, and other cities. Previously, they used simple traditional lifting tools, and the pain points were obvious – manual handling was time-consuming and labour-intensive, heavy glass panels were easily damaged, and high-altitude work posed significant safety risks. Construction efficiency often failed to meet project deadlines.

YG solution:
To address the client’s core needs for high-rise curtain wall construction and heavy glass lifting, we recommended the YG-LD-800 model heavy glass lifting equipment. This unit has a maximum load capacity of 800kg, a 4.5-metre ultra-high lift height, and 8 suction cups to ensure a firm, stable grip on large-area heavy glass panels.
During the communication phase, we explained the electric controls, power-off pressure retention, smart alarm, and other key functions in detail. We sent real-site operation videos and inspection reports, and answered their questions about European voltage compatibility, shipping, installation, and after-sales support. After visiting our factory for a live demo, they confirmed that the equipment fully met their project standards, and the deal was closed – they placed a bulk order for their curtain wall renovation projects.

Results:
After putting the equipment into use, the client saw significant improvements in quality and efficiency. Key data improved noticeably:

• Labour and efficiency boost: A job that used to take a team of 4 workers half a day now takes only 2 workers and 2 hours – overall efficiency increased by over 60%.
• Damage rate drop: Thanks to the stable vacuum suction system, issues like shifting, slipping, or breakage during heavy glass lifting were completely eliminated, reducing glass damage to below 0.5%.
• Total cost optimisation: The equipment supports repeated lifting, repositioning, and reuse without frequent tool changes. Labour and consumable costs are greatly reduced, helping the client deliver tight-schedule curtain wall projects on time.

Request Custom Solution

Case 2: Heavy Glass Lifting Equipment Optimises Workshop Slab Transfer Workflow

Client background:
The client is an Italian glass processing factory that produces tempered glass and marble decorative panels. Their core need was to solve the challenges of transferring heavy slabs and short-distance handling within the workshop. Their existing equipment had poor adaptability – heavy slabs tended to shift or get scratched during transfer, and the equipment lacked flexibility in narrow workshop aisles, seriously affecting production and shipping efficiency.

YG solution:
Based on the workshop environment and their handling needs, we recommended the YG-LD-500 model heavy glass lifting equipment – compact, flexible, and highly efficient for indoor use. It features electric walking with zero emissions and low noise, suitable for enclosed workshop spaces. The support arm can extend and retract freely, and the suction cups adjust to multiple angles, allowing precise pickup, transfer, and placement of heavy glass and marble panels. Regarding maintenance concerns, we explained that the suction cups are individually controlled and the modular design makes routine checks and repairs simple, minimising long-term upkeep costs.
After several rounds of detailed discussion and plan adjustments, the client fully recognised the equipment’s stability and suitability, and the purchase order was confirmed.

Results:
Once the equipment was in use, the factory experienced multiple significant improvements:

• Pain points solved: Common issues like jams, surface scratches, and positioning errors during heavy slab transfer were resolved, greatly improving workshop workflow.
• Production efficiency upgrade: Workshop slab handling efficiency increased by 55% overall, eliminating transfer bottlenecks and effectively raising daily shipment volumes.
• Strong stability: The equipment runs reliably with zero long-term failures, requiring minimal downtime for maintenance. It continuously supports the production line, earning long-term positive feedback and repeat-order interest from the client.

Speak with Our Product Manager

Key Maintenance Tips for Heavy Glass Lifting Equipment

Long-term stable operation of quality equipment relies on regular maintenance. For exported glass sucker machines, we have compiled simple, practical maintenance guidelines suited for overseas construction sites:

• Pre-operation check: Each day before starting, check suction cup sealing and vacuum valve sensitivity. Clean dust and debris off the cups to ensure stable suction and prevent operational hazards.
• Battery and circuit care: Regularly check battery levels and wiring connections to ensure the electric travel and electric lifting systems start and run smoothly.
• Post-operation cleaning: After each day’s work, clean the machine of dust and dirt, and park it in a dry, ventilated area to avoid moisture or rain that could corrode core components.
• Quarterly maintenance: Every quarter, inspect the hydraulic lifting system and rotation/tilt mechanisms. Apply special lubricating oil as needed to keep everything moving smoothly and extend service life.

Contact YG

YG Machinery focuses on building high-safety, high-efficiency, multi-scenario telehandler glass lifters, offering overseas customers one-stop procurement and after-sales support. Our core services and product advantages include:

• Full product range: All models support customisation and export compliance, with a steady supply of quality glass lifting machine for sale for international trade.
• One-on-one customisation: We match the right model and solution for different scenarios – curtain wall projects, workshop slab transfer, heavy specialmaterial lifting, and more.
• Full-service support: We provide end-to-end assistance from technical consultation, shipping and export, installation guidance, to after-sales maintenance – eliminating all post-purchase worries for overseas clients.
