Summers in Portugal are dry with little rain, and quarry crushing operations, construction site earthmoving, and large-scale agricultural and forestry spraying all face dust or efficiency challenges. Since the beginning of this year, YG Machinery has delivered mist cannon dust suppression equipment to two batches of customers in Portugal – one is a granite quarry in the Alentejo region, and the other is an agricultural, forestry and municipal service contractor near Lisbon. The two customers have different working conditions and chose different models, but both solved their respective problems with the same type of equipment. Below is the complete story of these two cases for your reference.

Click Here for a Free Quote

Mist Cannon Dust Suppression Parameters

Model	YG-20	YG-30	YG-40	YG-60
Spraying distance	20m	30m	40m	60m
Engine	electric	electric	electric	electric
Electric	380V/50HZ,3 phase	380V/50HZ,3 phase	380V/50HZ,3 phase	380V/50HZ,3 phase
Fan motor	3kw	3kw	4kw	11kw
Steering motor	2*1.5kw	2*1.5kw	2*1.5kw	2*1.5kw
Pump motor	1.5kw	1.5kw	2.5kw	7.5kw
Horizontal angle	360°	360°	360°	360°
Vertical angle	Minus10°-55°	Minus10°-55°	Minus10°-55°	Minus10°-55°
The nozzle	8	10	16	22
Cylinder material	Q235 Carbon steel	Q235 Carbon steel	Q235 Carbon steel	Q235 Carbon steel
Bucket		460L	480L	800L
Water consumption	1000L/h	1500L/h	3000L/h	7500L/h
Recycled water pipe	1400mm	1400mm	1400mm	1400mm
The machine size	1170*940*1700mm	1170*940*1800mm	1650*1200*2200mm	1700*1200*2200mm
Weight	200kg	250kg	300kg	350kg

Ask For Details

Case 1: Granite Quarry in Alentejo

Customer needs

• The quarry’s crushing and screening station generated heavy dust, and during the dry season the dust spread to nearby villages, resulting in multiple complaints from residents.
• Portugal’s environmental agency (APA) required the company to control fugitive dust emissions, and the customer needed a practical solution.
• Summer water use was restricted, so the customer did not want to rely on a large number of workers manually holding hoses for spraying.

YG solution
Based on the dust generation range of the crushing station, YG recommended the YG-40 model dust control water cannon: 40m range, 16 nozzles, water consumption 3000L/h. It was fixed next to the crusher, with 360° rotation covering the feed inlet, crusher, and belt transfer points, equipped with a 460L water tank connected to the on-site water supply.

Case process
In the first round of communication, the customer cared most about three things: whether the equipment had CE certification, whether the 380V/50Hz power supply matched the Portuguese grid, and how after-sales spare parts would be supplied. After YG provided the CE certificate, circuit diagrams, and a spare parts list, both parties confirmed the site conditions through a video meeting, and the customer signed the contract within one week. The equipment was shipped by sea to the Port of Sines, taking about 35 days in total. After arrival, the customer installed it themselves following video guidance, and YG engineers provided remote assistance for commissioning – it was put into operation the same day.

Results

• Visible dust at the crushing station was significantly reduced, and no further resident complaints were received after two months of operation.
• Compared with previous manual spraying, water consumption dropped by about 60%, and operators were reduced from 3 people to just 1 person working part-time to monitor the equipment.
• The unit ran stably and continuously in summer temperatures of up to 40°C without any failures.

Discuss Your Project

Case 2: Agricultural, Forestry and Municipal Service Contractor near Lisbon

Customer needs

• The contractor handled large-scale olive grove spraying and municipal green space maintenance, but traditional backpack sprayers were inefficient.
• They also undertook earthmoving projects and needed dust suppression equipment on site – they wanted one machine that could serve both purposes.
• Their budget was limited, so they preferred a model with moderate range and easy mobility.

YG solution
YG recommended the YG-30 model fog cannon dust suppression: 30m range, 10 nozzles, total weight 250kg, which could be transported easily by pickup truck. It could be used directly for pesticide spraying without any modification. For the customer’s potential future disinfection and epidemic-prevention work, YG also informed them that they should replace the pump with a ceramic one if spraying disinfectant.

Case process
This customer was actually a friend of the quarry owner in Case 1 – he saw the equipment in operation at the quarry and contacted YG through the existing customer referral. With a real-world case as proof, communication went very smoothly. The customer only confirmed two issues – chemical compatibility and water consumption – before placing the order, and they also purchased extra stainless steel nozzles as spares. The equipment arrived in Lisbon about 30 days after shipment.

Results

• Spraying efficiency in the olive groves improved dramatically – one machine could cover in one day what used to take a full week of manual work.
• When doing earthmoving projects, the same unit was moved to site for dust suppression – one machine for two uses, with very high utilization.

• The customer reported uniform atomization and easy remote control operation – workers could handle it after just half a day of training.

Request Custom Solution

Key Parameters You Need to Check Before Buying a Mist Cannon Dust Suppression

Based on these two cases, we suggest you focus on the following when purchasing:

1. Range and coverage area: Choose a range about 20% above the maximum radius of your dust-generating area. For fixed dust points like quarries, 40m or more is recommended; for agricultural spraying and small construction sites, 30m is sufficient.
2. Power supply conditions: All models are 380V/50Hz three-phase electric drive, which matches the EU grid standard. For remote sites without grid power, a generator set is required.
3. Water consumption: Ranges from 1000-7500L/h – in dry or water-scarce areas, select a model based on your water supply capacity.
4. Usage and configuration: Spraying pesticides can be done directly; spraying disinfectant requires replacing the pump with a ceramic one. In areas with poor water quality, we recommend adding a filter and keeping extra nozzles on hand.
5. Mobility needs: Customers who frequently move between sites should prefer lighter models of 200- 300 kg dust suppression fog cannons, while those working at fixed points can choose long-range models.

Contact YG

YG Machinery’s mist cannon dust suppression equipment has been exported to Portugal, Spain, and several other European countries, with full CE certification, and the 380V/50Hz power standard directly matches the EU grid. Whether you need a dust control water cannon for quarry and mine dust suppression, or a versatile solution combining agricultural spraying and construction site dust control, YG can provide model recommendations, spare parts support, and remote commissioning services. Contact YG today to get a quote for the fog cannon that fits your working conditions.
