When you need to move a 50-ton transformer, 100-ton bridge steel structure, or extra-long and extra-wide special-shaped equipment, traditional moving methods often fall short. Heavy equipment moving rollers are designed for such extreme working conditions. With modular assembly and wireless synchronous control technology, precise displacement of hundred-ton heavy loads becomes achievable. Compared with traditional forklifts or manual handling, battery powered load moving skates require no dedicated access and take up little floor space, enabling flexible operation in complex environments. YG Machinery supplies a full range of electric moving rollers from 10-ton to 60-ton, supporting multi-unit linkage to meet full-scenario demands ranging from factory relocation to engineering construction.
Battry Powered Load Moving Skates Specifications
| Model | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Motor | 500W x2Brake-equipped 104Reinforced flange gearbox | 750W x2Brake-equipped 104Reinforced flange gearbox | 1000W x2Brake-equipped 104Reinforced flange gearbox | 1200W x2 Brake-equipped 120 Reinforced flange gearbox | 1500W x2Brake-equipped 120Reinforced flange gearbox | 2000W x2Brake-equipped 120Reinforced flange gearbox | 3000W x2Brake equipped 120Reinforced flange gearbox |
| Controller | D2T80ADual-channel driver | D2T80ADual-channel driver | D2T100ADual-channel driver | D2T100ADual-channel driver | D2T200ADual-channel driver | D2T200ADual-channel driver | D2T220ADual channel driver |
| Remote Controller | C7 Remote Controller | C6/C7 Remote Controller or Industrial Remote Controller | C7 Remote Controller | C7 Remote Controller | C6/C7 Remote Controlleror Industrial Remote Controller | C7 Remote Controlleror Industrial Remote Controller | C7 Remote Controlleror Industrial Remote Controller |
| Battery Spec | 48v 30AHTernary lithium | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium |
| Working Current | 25A | 60A | 60A | 60A | 120A | 120A | 120A |
| Charging Current | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 |
| Drive Wheel | 80*120x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 140x140x4High-hardness fully imported polyurethane | 140x140x4High-hardness fully imported polyurethane | 140x140x8High-hardness fully imported polyurethane |
| Gear | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module |
| Plate Material | 10mmQ355 manganese steel plate | 10mmQ355 manganese steel plate | 12mmQ355 manganese steel plate | 12mmQ355 manganese steel plate | 16mmQ355 manganese steel plate | 16mmQ355 manganese steel plate | 16mmQ355 manganese steel plate |
| Towing Weight | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Load Capacity | 10T | 10T | 12.5T | 15T | 20T | 25T | 30T |
| Overall Dimension | 500x550x145mm | 670x620x165mm | 670x635x165mm | 740x640x185mm | 810x800x182mm | 810x800x182mm | 1110x800x185mm |
| Disc Flange | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter |
| Travel Speed | 2-10m/min adjustable | ||||||
| Continuous Working Time | 2-3 hours | 3-4 hours | 3-4 hours | 3-4 hours | 4-5 hours | 4-5 hours | 4-5 hours |
How Does Heavy Equipment Moving Dolly Handle Complex Working Conditions?
Slope Operation Capacity
Equipped with high-torque motors and imported polyurethane drive wheels, the unit runs stably on slopes up to 15 degrees. Luomengtai high-strength gears work with reinforced flange gearboxes to guarantee power output and braking safety during heavy-load climbing. Even on slippery ground, high-hardness polyurethane wheels deliver sufficient grip.
Maneuverability in Narrow Spaces
Independent wheel drive enables 360-degree in-place turning. The zero-turn-radius design allows the unit to move flexibly inside narrow workshops. The wireless control feature of remote control electric transporter lets operators adjust positions precisely from a safe distance without extra turning clearance.
Complex Terrain Adaptability
Battery powered load moving skates need no external power supply and can operate on unpaved construction sites and temporary access roads. Q355 manganese steel body plus reinforced flange structure ensures load-bearing stability on rough ground.
Multi-unit Synchronization
Supports wireless linkage of up to four main units. The main control unit synchronizes speed and direction. When moving extra-long or extra-wide loads, synchronized multi-unit operation keeps loads steady and avoids overloading or shifting at single points.
Heavy Equipment Moving Rollers Operating Instructions
Standard 3-Point Support (Recommended)
The combination of 1 main unit + 2 auxiliary rollers is the most common setup, covering over 90 % of moving tasks. Place the main unit near the load’s center of gravity and position two auxiliary rollers on both sides to form a stable triangular support. This configuration offers flexible steering and simple operation.
4-Point Stable Setup
Use 2 main units + 2 auxiliary rollers or 4 linked main units for high-center-of-gravity or large-base loads. Four-point support provides better stability yet slightly less steering flexibility than the 3-point method.
In-place Translation
Link 3 or 4 main units to realize 360-degree in-place translation of loads. Ideal for high-precision installation work such as machine tool positioning and mold change-over.
Remote Controller Options
- C7 Remote Controller: Basic model, supports high/low speed shift and forward-backward-left-right control. Powered by 4 AA batteries or a power bank.
- Industrial Remote Controller: Professional model, features 0-10 speed fine-tuning, emergency stop, and cruise control. Built-in rechargeable battery; one-hour charging supports full-shift operation.
Suitable Industries for Heavy Equipment Moving Rollers
Factory & Precision Manufacturing
- Intra-workshop relocation and installation of heavy machine tools and injection molding machines
- Precision transfer of large aerospace components
- Segment assembly operations in shipbuilding
Warehouse & Logistics Hub
- Stacking and handling of steel coils and aluminum coils
- Moving and positioning of large molds
- Short-distance transfer of port containers
Engineering & Energy Construction
- Positioning and transportation of transformers and generators
- On-site shifting of precast components and bridge steel structures
- Transport and installation of wind-power equipment
Special-condition Applications
- Clean-room handling for dust-free workshops
- Special-configured moving for explosion-proof zones
- Restricted-space operation in narrow tunnels
What Factors Affect Remote Control Electric Transporter Prices?
Tonnage Specification: The 10T base model has the lowest price. Higher tonnage brings upgraded motor power, battery capacity, and body strength, which push up costs accordingly.
Remote Controller Configuration
The C7 remote controller is standard and lower cost. The industrial remote controller adds speed fine-tuning, emergency stop, and cruise control, costing 20-40 % more.
Battery Type
Ternary lithium battery is standard. Lithium iron phosphate offers longer cycle life (2000 cycles vs 1000 cycles), yet costs 20-30 % higher.
Order Quantity
Single-unit orders follow standard pricing. Bulk orders (3 units or above) qualify for discounts. Purchase multi-linkage sets in one order to guarantee system compatibility.
Custom Requirements
Special configurations such as high-temperature resistance, explosion-proof, and dust-proof require customization. Quotation is subject to detailed requirements.
FAQ About Heavy Equipment Moving Rollers
Q1: What is the running time of heavy equipment moving rollers?
A: 2-3 hours for 10T model; 3-4 hours for 20-30T models; 4-5 hours for 40-60T models. Actual runtime depends on load weight and work intensity. Spare battery packs are recommended for multi-shift work.
Q2: What is the difference between the C7 remote controller and an industrial remote controller?
A: The C7 remote controller provides basic directional control and speed shift, powered by AA batteries or a power bank. The industrial remote controller supports 0-10 speed fine-tuning, emergency stop, and cruise control with a built-in rechargeable battery for one full work shift. The industrial version of remote control electric transporter fits heavy-duty frequent-use scenarios.
Q3: What is the maximum climbable slope?
A: Normal operation on slopes within 15 degrees. Reduce load weight or select higher-tonnage units on steeper slopes for safety. Polyurethane wheels deliver best grip on dry surfaces.
Q4: How to pick the right setup?
A: The “1 main unit + 2 auxiliary rollers” 3-point support is recommended for most cases. Choose “2 main units + 2 auxiliary rollers” or “4 linked main units” for heavy or over-size loads. Link 3 or 4 main units if in-place translation is needed.
Contact YG for Professional Moving Solutions
YG Machinery’s heavy equipment moving rollers have been successfully deployed in hundreds of global projects. Whether you need single-unit handling or multi-unit linkage solutions, YG delivers full-cycle support including condition analysis, solution design, and after-sales service. Contact us now to get your custom electric moving solution and the latest quotation.
