A public transportation operator in Manila, the Philippines, intends to provide a stable, efficient, and tropical climate-adaptable fast charging solution for its growing fleet of electric buses and diverse electric vehicle models. The comprehensive solution of Electric Fast Charger provided by YG Machinery has successfully met their needs.【WhatsApp/WeChat/Phone】+86 13837122632
Electric Fast Charger Parameters
| Product number | YG-60KW | YG-80KW | YG-120KW | |
| Detailed specification | rated power | 60KW | 80KW | 120KW |
| Charging equipment | User Interface | 7-inch LCD color display touchscreen | ||
| installation | Floor-standing/Down in down out | |||
| Routing mode device size | 635*423*1600(mm) | |||
| Input voltage | AC380V±20% | |||
| Input frequency | 45~65Hz | |||
| The output voltage | 200-750VDC | |||
| Single gun output current range | 200V-500V | 200V-500V | 200V-500V | |
| The output voltage | 0-90A | 0-120A | 0-160A | |
| Single gun output current range | 200V-750V | 200V-750V | 200V-750V | |
| The output voltage | 0-60A | 0-80A | 0-107A | |
| Charging equipment | Single gun output current range | 0-112A | 0-150A | / |
| Cable length | 5m | |||
| Electrical index | Measurement accuracy | Level 0.5 | ||
| Current limit protection value | ≥110% | |||
| Voltage regulation accuracy | ≤±0.5% | |||
| Steady flow accuracy | ≤±1% | |||
| Ripple coefficient | ≤±0.5% | |||
| effectiveness | ≥94.5% | |||
| Power factor | ≥0.99 (50% load or more) | |||
| Harmonic content THD | ≤5% (50% load or more) | |||
| Feature design | HMI | 7-inch LCD color display touch screen, LED indicator | ||
| Charging mode | Auto full / fixed power / fixed amount / fixed time | |||
| payment method | Credit card payment / APP payment /scan code payment | |||
| Communication Interface | Ethernet 2/3/4G (optional) | |||
| Safety design | Executive standard | GB\T 20234, GB/T 18487, GB/T 27930, NB\T 33008 | ||
| security function | Charge gun temperature detectionovervoltage protectionundervoltage protectionoverload protectionshort circuit protectiongrounding protectionover temperature protectionlow-temperature protectioninsulation monitoring protectionpolarity reverse connection protectionlightning protectionemergency stop protectionleakage protection | |||
| Environmental indicators | Operating temperature | -25°C~+50°C | ||
| Working humidity | 5%~95% non-condensing cream | |||
| Working elevation | <3000m | |||
| Protection level | IP54 | |||
| cooling method | Forced air cooling | |||
| Noise control | ≤60dB | |||
| MTBF | 100,000 hours | |||
Why YG Electric Fast Charger Becomes a Reliable Choice?
The climate in the Philippines, characterized by high temperature, high humidity, frequent typhoons, and unstable power grid environment, poses a severe test for charging equipment. Our equipment has won the customer’s trust through the following targeted designs:
- Tough Against Harsh Environments: IP54 protection level plus high-performance flame-retardant casing resists moisture, salt spray and dust. Wide input voltage (AC380V±20%) handles local voltage fluctuations, ensuring continuous service in unstable grid areas.
- Smart Remote Management: Integrated IOT tech and self-service charging cloud platform let customers monitor equipment status, charging data and revenue in real time at headquarters. OTA remote upgrades avoid on-site visits for future optimizations, cutting overseas O&M costs.
- Localized User-Friendly Interaction: 7-inch multilingual touchscreen connects seamlessly with QR code mobile payment, matching users’ mobile-reliant habits. Each fast electric charger features simple, intuitive operations, boosting user experience and operational efficiency.
Flexible Deployment of Multi-Power Electric Fast Charger
This project was implemented in phases at multiple bus stations and transportation hubs in Manila. The flexibility of YG quick charge for electric cars has been fully demonstrated:
- High-Power Deployment at Core Stations: At major bus hubs, YG-120KW high-power Electric Fast Chargers are installed to ensure that electric buses can quickly get charged in a short time, supporting the high-intensity bus operation schedules.
- Flexible Configuration at Mixed Stations: At comprehensive stations serving electric buses, logistics vehicles, and taxis simultaneously, YG-80KW and YG-60KW equipment are deployed in a mixed manner to form an efficient fast charger for ev car matrix, meeting the charging needs of different vehicle models at different time periods.
Professional Support and Installation Training
To ensure the success of the project, YG Machinery dispatched an engineer team to provide on-site installation guidance and conducted systematic training for the local operation and maintenance team. The training covered daily equipment operation, basic fault diagnosis, and data management and report generation using the cloud platform, ensuring the customer’s long-term independent operation capability.
Quick Charge for Electric Cars Improves Operational and Financial Efficiency
Since its operation, the Electric Fast Charger solution provided by YG has achieved significant benefits:
- Greatly Improved Operational Efficiency: The average charging time of the fleet has been reduced by approximately 65%, and the vehicle utilization rate and operating mileage have increased significantly.
- Intelligent Management: The remote monitoring and online meter reading functions make asset management clear and transparent, and improve the efficiency of financial reconciliation.
- Optimized Total Operational Costs: The high reliability of the equipment reduces failure rates and maintenance costs, and the intelligent charging strategy also helps to balance the power grid load and save energy expenses.
Fast Electric Charger Drives the Future of Sustainable Transportation
With its excellent environmental adaptability, intelligent management capabilities, and reliable performance, the Electric Fast Charger of YG Machinery has successfully helped its Philippine partner build a green fast charging network for the future. This case proves that our product is an ideal fast charger for ev car choice to cope with complex global markets.
Contact Us
If you plan to deploy charging infrastructure in the Philippines or other overseas markets and are looking for a reliable quick charge for electric cars partner, YG Machinery is willing to provide you with customized solutions with mature products and rich project experience. Please contact us immediately to discuss cooperation.【WhatsApp/WeChat/Phone】+86 13837122632
