As a plant manager or equipment maintenance supervisor, you know exactly what heavy-equipment moving involves: forklift operators, signal persons, ground support staff — at least five to six workers, sometimes more than ten. Safety risk assessments, path clearance, equipment securing- every step must be handled carefully. YG’s load moving skates bring a brand-new option for this high-cost, high-risk work. One person, one remote controller, and one unit can finish tasks that once required an entire team. This article shows the outstanding real-world performance of load moving skates through two genuine customer cases from the United States.
Load Moving Skates Specifications
| Model | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Motor | 500W x2Brake-equipped 104Reinforced flange gearbox | 750W x2Brake-equipped 104Reinforced flange gearbox | 1000W x2Brake-equipped 104Reinforced flange gearbox | 1200W x2 Brake-equipped 120 Reinforced flange gearbox | 1500W x2Brake-equipped 120Reinforced flange gearbox | 2000W x2Brake-equipped 120Reinforced flange gearbox | 3000W x2Brake-equipped 120Reinforced flange gearbox |
| Controller | D2T80ADual-channel driver | D2T80ADual-channel driver | D2T100ADual-channel driver | D2T100ADual-channel driver | D2T200ADual-channel driver | D2T200ADual-channel driver | D2T220ADual-channel driver |
| Remote Controller | C7 Remote Controller | C6/C7 Remote Controller or Industrial Remote Controller | C7 Remote Controller | C7 Remote Controller | C6/C7 Remote Controller or Industrial Remote Controller | C7 Remote Controller or Industrial Remote Controller | C7 Remote Controller or Industrial Remote Controller |
| Battery Spec | 48v 30AHTernary lithium | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 60AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium or Lithium iron phosphate | 48V 120AHTernary lithium |
| Working Current | 25A | 60A | 60A | 60A | 120A | 120A | 120A |
| Charging Current | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 | 54.6 |
| Drive Wheel | 80*120x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 90x135x4High-hardness fully imported polyurethane | 140x140x4High-hardness fully imported polyurethane | 140x140x4High-hardness fully imported polyurethane | 140x140x8High-hardness fully imported polyurethane |
| Gear | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module | Luomengtai high-strength gear3-module |
| Plate Material | 10mmQ355 manganese steel plate | 10mmQ355 manganese steel plate | 12mmQ355 manganese steel plate | 12mmQ355 manganese steel plate | 16mmQ355 manganese steel plate | 16mmQ355 manganese steel plate | 16mmQ355 manganese steel plate |
| Towing Weight | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Load Capacity | 10T | 10T | 12.5T | 15T | 20T | 25T | 30T |
| Overall Dimension | 500x550x145mm | 670x620x165mm | 670x635x165mm | 740x640x185mm | 810x800x182mm | 810x800x182mm | 1110x800x185mm |
| Disc Flange | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter | 2900MM Diameter |
| Travel Speed | 2-10m/min adjustable | ||||||
| Continuous Working Time | 2-3 hours | 3-4 hours | 3-4 hours | 3-4 hours | 4-5 hours | 4-5 hours | 4-5 hours |
Case 1: Workshop Relocation Challenge for a Heavy-duty Machinery Manufacturer in Texas
Customer Background
A large heavy-duty machinery manufacturer based in Houston, Texas, mainly produces oil-field drilling equipment and large pressure vessels. At the end of 2025, the company planned to move one heavy injection-molding production line entirely from Zone A to the newly built Zone B. The project involved five units with a total weight of over 150 tons, and the heaviest injection-molding machine weighed 45 tons. The narrowest aisle inside the workshop was only 1.2 meters wide, where conventional forklifts could not pass. Besides, multiple slopes and floor joints existed on site.
YG Solution
After receiving the customer inquiry, YG’s technical team quickly carried out a remote condition assessment. Considering load weight and space constraints, we recommended a four-point support solution for load moving skates: 2 main units plus 2 auxiliary rollers, paired with an industrial remote controller. The core advantage of this solution lies in the fact that heavy equipment moving rollers adopt independent wheel drive for 360-degree in-place turning. Its zero-turn-radius design allows flexible travel through the 1.2-meter-wide aisle. Multi-unit linkage keeps the 45-ton load moving steadily on slopes without local overload or shifting.
Case Process
The customer found YG’s official website by searching “heavy equipment moving dolly” on Google. During initial communication, the customer shared that they had tried forklifts and manual rollers before. Forklifts could not enter narrow aisles, while manual rollers required 12 workers for two full days to move one single machine. YG sales engineers demonstrated remote-control operation and multi-linkage principles of remote control electric transporter in a video conference. The customer highly recognized the safety brought by the 50-meter remote range and one-person operation. After two rounds of technical review and price negotiation, the customer finally ordered four 40T units of load moving skates together with matching industrial remote controllers. The whole process from first inquiry to order confirmation took three weeks.
Application Result
After equipment delivery, YG provided remote installation guidance and operation training. According to customer feedback, moving one machine once took 12 workers two days in the past. Now, only one operator with remote control plus two support staff can finish the task within 4 hours. The 360-degree in-place turning function of heavy equipment moving rollers allows position adjustment without reversing inside narrow aisles.
Case 2: Precision Component Transfer for an Aerospace Supplier in California
Customer Background
An aerospace component supplier near Los Angeles, California, supplies large composite structural parts for Boeing and Airbus. The company needed to transfer a 28-ton composite mold from the curing-oven area to the machining center inside a clean-room, for a distance of around 80 meters. The workshop floor was coated with epoxy resin, which set strict requirements for equipment cleanliness and floor protection. Precision machines and pipelines were placed on both sides of aisles; any collision could cause millions-of-dollar losses.
YG Solution
For clean-room and high-precision requirements, YG recommended a three-point support solution of load moving skates: 1 main unit plus 2 auxiliary rollers, fitted with high-hardness polyurethane drive wheels. This material will not scratch epoxy floors or leave black scuff marks. Meanwhile, the 0-10 level fine speed adjustment on the industrial remote controller lets operators tune moving speed precisely and avoid impact on precision molds caused by sudden start-stop.
Case Process
In the first inquiry, the customer described moving requirements and the clean-room environment in detail, and emphasized strict standards for floor protection and operation accuracy. The customer mentioned previous manual attempts: moving the 28-ton mold on epoxy flooring was extremely difficult. Each transfer needed 8 workers and over 3 hours, with risks of floor scratches.
On the very day of receiving the inquiry, YG sales engineers scheduled an online meeting. We learned the workshop layout, aisle width, floor material, mold dimensions, and weight via video call. Based on these details, the YG technical team worked out a complete moving solution within one week, including model selection (2 units of 20T), three-point support setup, industrial remote-controller configuration, and travel-route planning.
The customer spoke highly of our professional proposal. Two further rounds of discussion covered after-sales service, operation training, and spare-part supply. YG promised remote installation guidance and online training. After confirming all terms, the customer placed a formal order for two 20T units of load moving skates plus matching industrial remote controllers. The whole cycle from initial inquiry to order confirmation took four weeks.
Application Result
After commissioning, the customer reported the following improvements: single transfer time dropped from over 3 hours to 40 minutes; required operators reduced from 8 to 1. Precise speed control from heavy equipment moving rollers kept molds free from vibration during transit, raising finished-product yield by roughly 5 %. The customer commented that load moving skates not only solved their moving headache but also became a key part of their lean-manufacturing upgrade.
Why Choose YG’s Remote Control Electric Transporter?
- Safe & Reliable: 50-meter wireless remote keeps operators away from heavy loads to eliminate crush and collision risks. Industrial remote controllers are equipped with emergency stop and cruise control for multi-layer operational safety.
- Flexible & Efficient: 360-degree in-place turning and zero-turn-radius design enable heavy equipment moving rollers to maneuver freely inside narrow workshops and tight aisles. 2-10 m/min stepless speed adjustment supports precise movement.
- Strong Power: Full-range capacity from 10T to 60T, capable of handling slopes up to 15 degrees. Q355 manganese-steel body and Luomengtai high-strength gears resist deformation under long-term heavy-load service.
- Modular Assembly: Supports wireless multi-unit linkage for flexible setup according to load dimensions. Suitable for extra-long bridge steel structures as well as irregular large castings.
Contact YG for Your Custom Moving Solution
From heavy-machinery manufacturers in Texas to aerospace suppliers in California, YG’s load moving skates have been successfully deployed across multiple U.S. industries. Whether you need to relocate heavy machine tools, large transformers, or precision molds, YG delivers end-to-end support including site assessment, solution design, and after-sales training. Our full-series units cover 10T-60T, with flexible options for C7 remote controllers or industrial remote controllers. Contact us today for your custom electric moving solution and the latest quotation.
